120mm Rockwool High Performance Partial Fill Cavity Slab ( Pack of 5 )

The 120mm Rockwool High Performance Partial Fill Cavity Slab offers a semi-rigid insulation solution specifically tailored for masonry cavity wall construction.

With a Euroclass A1 rating, the 120mm Rockwool Partial Fill Cavity Slab engineered to deliver both thermal efficiency and straightforward installation. Its dual-density composition effectively absorbs irregularities on the inner leaf while providing a durable outer surface for securing retaining clips. These attributes contribute to the durability of external wall constructions, ensuring prolonged energy efficiency and reducing heat loss by preventing gaps in the insulation layer.

Product specification

• Thickness: 120mm
• Length: 1200mm
• Width: 455mm
• Board Coverage: 0.546
• Pack Coverage: 2.78 m2
• Pack Quantity: 6
• Thermal Conductivity: 0.034 W/mK
• Application: Cavity Wall Insulation
• Features: Fire Protection
• Fire Protection: Non-Combustible
• Material: Mineral Wool
• Application: Masonry and framed cavity wall construction
• Product standards: BS EN 13162
• CE Marking: CE Marked
• BBA Approved: Certificate 93/2884
• Water repellent: Yes
• Water vapour resistance: Negligible

Features & Benefits: ROCKWOOL Partial Fill Cavity Slab 120mm

• Ideal for masonry and framed cavity wall construction, including high-rise buildings.
• Classified as non-combustible with a Euroclass A1 rating, ensuring superior fire safety.
• Enhances thermal performance, contributing to energy efficiency.
• Water-repellent with a robust front-face design to resist damage and ensure longevity.
• Slabs interlock to effectively close gaps, minimizing heat loss.
• Semi-rigid 120mm partial fill insulation solution for ease of installation and durability.
• Dimensions: 1200mm length x 455mm width x 120mm thickness.
• Coverage of 27.3m² per pallet.
• Thermal conductivity of 0.34 W/mK, providing effective insulation properties.
• Suitable for use in all exposure zones with a residual cavity width of 120mm or greater. In areas with severe exposure, additional measures such as external render coats may be necessary, following standard practices.

Applications

Buildings up to and including 12 metres:

• The product is suitable for use in any exposure zone where a residual cavity width of 120mm or greater is maintained. However, it's important to note that the use of the product does not eliminate the necessity of applying an external render coat or other appropriate finish in severe exposure zones where such application is customary.
• During construction, the minimum residual cavity width to be preserved must be 25mm. To meet this requirement, it may be necessary to specify a greater nominal residual cavity width at the design stage to accommodate inherent inaccuracies in the building process. For instance, the NHBC mandates a nominal residual cavity width of 80mm when adhering to normal standards of tolerance and workmanship.

Buildings over 12 metres in height: For buildings over 12 metres in height, a minimum residual clear cavity width of 120mm should be achieved, with the following specifications:

• Continuous cavity walls from ground level must not exceed a maximum height of 12 metres.
• Above 12 metres, continuous cavity walls should not surpass a maximum height of 7 metres.
• Breaks in the form of continuous horizontal cavity trays discharging to the outside are required in both cases.
• If the cavity width is reduced for structural reasons, such as by the intrusion of ring beams, a minimum residual cavity width of 25mm must still be maintained. Additionally, extra caution must be exercised with fixings and weatherproofing, such as the inclusion of a cavity tray.

Benefits

120mm Rockwool Partial Fill Cavity Insulation offers a stable and durable solution for the thermal insulation of external walls.

Just like stone, 120mm Rockwool Partial Fill Cavity stone wool insulation is durable by nature. Lasting 65 years (and counting), its performance is unaffected by weather, humidity, temperature changes or compression - and needs no technical supervision or refurbishment.

More Information on 120mm Partial Fill Cavity Slab

• Manufaturer Link: Rockwool Twin Roll
• 120mm Rockwool Partial Fill Cavity Slab is a high-performance brand offering versatile applications.
