120mm Unilin Thin-R FR-BGM Flat Roof Board ( Pack of 3 )

The 120mm FR-BGM Flat Roof Insulation Board from Unilin features a polypropylene fleece on the exterior, complemented by a bitumen/glass fibre working surface. The underside is covered with a mineral glass facing. This product is part of Unilin's extensive collection of high-performance 120mm flat roof boards, offering complete solutions for various flat roof projects.

120mm Unilin FR-BGM Flat Roof Board was previously known as 120mm Xtratherm FR-BGM.

Product Specification

Brand: Unilin / Xtratherm®

Model: 120mm FR/BGM

Thickness: 25mm,30mm,40mm, 50mm, 60mm, 70mm, 80mm, 100mm, 110mm, 120mm, 130mm, 140mm, 150mm

Length: 1200mm

Width: 600mm

Board Coverage: 0.72m2

Pack Coverage: 2.16 m2

Pack Quantity: 3

R-Value: 5 m2K/W

Thermal Conductivity: 0.024W/mK

Compressive Strength: 150kPa

Dimensions: 1,200mm x 600mm x 120mm

Colour: Yellowish

Density: 32kg/m3

Material: Polyisocyanurate (PIR Insulation)

Profile: Square Edge

Inner facing: Mineral Glass

Outer facing: Bitumen/glass fibre

Shipping method: Articulated Vehicle ǀ Courier

Applications: Flat Roof

BBA Certified: Yes (No. 11/4878)

ETA Notification: Yes

Features: Thermally efficient flat roof board

About

120mm Unilin Thin-R FR-BGM , a component of Unilin's extensive range of high-performance flat roof boards, offers several benefits for flat roof projects:

1. High thermal performance: The 120mm FR-BGM provides excellent insulation properties, helping to maintain optimal temperature levels within the building.
2. Compatibility with most bituminous based roofing systems: This product is designed to work seamlessly with a wide variety of bituminous roofing systems, ensuring ease of integration into existing structures.
3. Fleece finished bitumen/glass fibre facings: The polypropylene fleece finished bitumen/glass fibre working surface enhances the durability and resilience of the 120mm Flat Roof BGM, providing a reliable and long-lasting solution.
4. Environmental Product Declaration (EPD) certification: 120mm Unilin's Flat Roof Insulation Board BGM has obtained an EPD certification from the IGBC (International Green Building Council). For more detailed information, please reach out to the technical support team.

Key Points:

1. Offers excellent thermal performance.
2. Features fleece finished bitumen/glass fibre facings.
3. FR-BGM is suitable to apply torch on felt directly on the insulation.
4. Compatible with a wide range of bituminous based roofing systems.

Roof Design

The 120mm Xtratherm/Unilin Insulation Boards provided are compatible with a wide range of bitumen-based waterproofing systems. These systems typically involve a BS EN 13707:2013 type 3G perforated base layer or a proprietary system for roof waterproofing. When using the boards, it is recommended to have the fleece side facing upwards. Alternatively, full bonding is also an option. For guidance on managing moisture and condensation, it is advisable to follow the guidelines outlined in BS 8217 for reinforced bitumen membranes used in roofing applications.

Falls

The fall on a flat roof should be designed to ensure that rainfall does not pond.

Roof Loading

Our 120mm Xtratherm / Unilin FR/BGM are designed for roof decks that experience minimal foot traffic and require limited maintenance. In cases where regular pedestrian access is necessary, walkways should be installed on the roof. Once the roof construction is finished, it is advisable to lay protective boarding if there is a need for additional work to be conducted on the site. This will help safeguard the integrity of the roofing system.

Roof Finish

Built up roofing systems should be finished with a suitable reflective layer such as chippings. Advice should be sought from system manufacturer.

Fire Performance

The fire rating, when tested to EN 13501-5 and BS 476 Part 3 ‘External Fire Exposure Roof Test’, will be dependent upon waterproofing system specified.

Vapour Control Layer

Decks should be primed before the application of the hot bitumen used to bond the vapour control layer. Reference should be made to BS 8217 when applying the vapour control layer. Carry the VCL past the insulation and seal with the parapet wall.
