130-150mm Unilin Thin-R TR/MG Tapered Roof Insulation Board ( Pack of 2 )

The 130-150mm Unilin ( Xtratherm )TR/MG Tapered Roof Insulation is a top-performing roofing material made of Polyisocyanurate with mineral coated glass facers. It is designed to be used beneath single-ply fully adhered roof membranes, single-ply waterproofing systems, and partially bonded built-up felt. This product has an Environmental Product Declaration (EPD) certified by IGBC, and if you need more information, please reach out to our technical support team.

Product Specification

Range: 130-150mm TR/MG

Thickness: 30-50mm, 50-70mm, 70-90mm, 90-110mm (1:60)

Length: 1200mm

Width: 1200mm

Board Size: 1200mm x 1200mm

Pack Size: 2 sheets

Pack Coverage: 2.88m2

Pack Weight: 12kg

Thermal conductivity: 0.024 – 0.027 (WmK)

Compressive Strength: >150 kPa @ 10% compression

Material: PIR

Inner facing Mineral coated glass facer

Outer facing Mineral coated glass facer

Application: Flat Roof insulation

Density (Foam Core): 32 kg/m3

Reaction to Fire: Euroclass E

Features & Benefits: Xtratherm TR/MG Tapered Roof Board 130-150mm

1. Dimensions: 1200mm length x 1200mm width x 130-150mm thickness
2. Fall: 1:60
3. Suitable for refurbishment projects and new builds
4. Ideal for full bonding with an approved adhesive
5. Environmentally friendly: Zero Ozone Depletion Potential (ODP), Low Global Warming Potential (GWP), and non-deleterious materials
6. Compressive Strength: >150 kPa @ 10% compression
7. Compatible with adhesively bonded single ply roofing membranes installed on mechanically fixed boards
8. Each board covers an area of 1.44m²
9. This pack contains four boards, covering a total area of 5.76m²
10. Foam core density: 32kg/m³

Features and Benefits:

1. Versatile solution suitable for both refurbishment projects and new construction
2. Offers excellent dimensional stability and durability
3. Easy to install and fully bond using approved adhesives
4. Environmentally conscious choice with zero ODP and low GWP
5. Complies with non-deleterious materials standards
6. Strong compressive strength to withstand load and pressure
7. Compatible with adhesively bonded single ply roofing membranes
8. Efficiently covers a significant area with each board
9. High-quality foam core with a density of 32kg/m³ for reliable performance.

Vapour control layer

A vapour control layer lapped and sealed should be used below the insulation Board. When using fully adhered systems, board joints should be taped subject to adhesive system being used.

Bonded boards

The insulation boards are embedded in a layer of bitumen on a 3G type felt to BS EN 13707: 2013 (Flexible sheets for waterproofing. Reinforced bitumen sheets for roof waterproofing that has been adhered to the deck. (Unilin recommend that all systems should have mechanical fixings included or be adhered using other suitable adhesive)
