20mm Unilin Thin-R XT/UF PIR Floor Insulation Board

Introducing the 20mm Unilin Thin-R XT/UF PIR Floor Insulation Board - a rigid PIR insulation board designed specifically for floor construction applications. This product has garnered popularity among contractors and installers for good reason: it offers comparable performance to renowned brands like Kingspan TF70 but comes at a significantly more affordable price.

With an impressive thermal performance rating of 0.022W/mK and a compressive strength of 140kPa at 10% compression, this 20mm floor insulation board delivers exceptional results while maintaining its structural integrity even under pressure. It's an ideal choice for effective and cost-efficient floor insulation solutions.

Product Details

Brand: 20mm Unilin XT/UF

Thickness : 20mm

Lenght: 2400mm

Width: 1200mm

Overal Thickness:15mm,20mm,25mm,30mm,35mm,40mm,45mm,50mm,60mm,65mm,70mm,75mm,80mm, 90mm,100mm,110mm,120mm,130mm,140mm,150mm,160mm,165mm

Maximum board weight: 0.45 kg/m2

Thermal Resistance : 0.68m2K/W

Thermal conductivity: 0.022 W/mK

Compressive strength: >150 kPa

Water Vapour Resistivity: >100 MNs/gm

Density (Foam Core):30-32 Kg/m3

Surface spread of flame: Class 1

Reaction to fire: E

Finish: Aluminium Foil Facings

Applications: Ground Supported & Suspended Floors

ETA Notification: Yes

Features: Versatile ǀ High-performance ǀ Rigid

Key Points

1. High compressive strength
2. Suitable for underfloor heating
3. Perimeter strips for robust detailing
4. Reduced insulation thickness
5. Low emissivity foil facings

About

Inadequately insulated floors in buildings lead to substantial heat loss. However, with our 20mm XT/UF Thin-R Underfloor Insulation , this issue is effectively addressed as it greatly enhances the U-Value of both new and existing floors.

20mm Unilin / Xtratherm XT/UF offers a lightweight and simple installation process. It boasts an impressive combination of high compressive strength and low thermal conductivity, making it an optimal choice for superior floor insulation board and overall performance.

Info
