30mm Kingspan Thermafloor TF70 Floor Insulation

30mm Kingspan Thermafloor TF70 boasts exceptional performance as a floor insulation board, featuring a low thermal conductivity of 0.022 W/mK. It can be applied to both solid and suspended floors and is applicable to both new construction and renovation projects. These 30mm insulation boards are simple to handle and cut, streamlining the installation process. They come in a variety of thicknesses to suit different requirements.

Amongst the more thermally efficient 30mm floor insulation Boards, this lightweight insulation is easy to transport, handle and install, and is suitable for use with most underfloor heating systems, potentially reducing the cost of related items such as soil removal and service connections.

Properties

Brand: Kingspan

Thickness: 30mm

Length: 2400mm

Width: 1200mm

Weight: 1.84kg | Thermafloor TF70 has an approximate weight of 3.50 kg/m2 at a thickness of 30 mm.

Model: 30mm Thermapitch TF70

Dimensions: 2,400mm x 1,200mm x 30mm

Compressive Strength: The compressive strength typically exceeds 140 kPa at 10% compression.

Density: 32 Kg/m3

Length: 2400mm

Material: Polyisocyanurate (Kingspan PIR Insulation)

R-Value: 1.35m2K/W

Size: 1200mm x 2400mm

Thermal Conductivity: 0.022 W/mk

Finish: 30mm TF70 is faced on both sides with a low emissivity composite foil, autohesively bonded to the insulation core during manufacture.

Applications: High performance floor insulation.

Fire Resistance: Under System 4 AVCP, 30mm Thermafloor TF70 has a Euroclass rating of F.

Water vapour resistance: 110 MNs/g

BBA Certified: Yes, No. 14/5133

Features: Improves the Thermal Resistance | Unaffected by air infiltration | Resistant to the passage of water vapour

Here are some "Applications":

The 30mm insulation has a diverse range of applications, including use in solid concrete ground-based floors, beam and dense block floors, suspended timber ground floors, and timber floors on battens.

The Facings

During the manufacturing process, Kingspan 30mm PIR is bonded with a low emissivity composite foil on both sides, which serves as a reflective surface to enhance the thermal resistance of any unventilated cavity next to the board.

The Core

30mm Kingspan Thermafloor TF70 core is made using Nilflam® technology, which is a top-quality fiber-free rigid thermoset polyisocyanurate (PIR) insulant. The manufacturing process uses a blowing agent with zero Ozone Depletion Potential (ODP) and low Global Warming Potential (GWP).

Compressive Strength

When tested to BS EN 826:2013 (Thermal insulating products for building applications. Determination of compression behavior), 30mm Kingspan PIR insulation usually surpasses a compressive strength of 150 kPa at 10% compression.

Water vapour resistance

Under BS EN 12086:2013 (Thermal insulating products for building applications. Determination of water vapor transmission properties) testing, this product typically achieves a resistance significantly exceeding 100 MNs/g.

Durability

The durability of 30mm TF70 Floor Insulation depends on appropriate installation, supportive structure, and usage circumstances. If installed correctly, it has the potential to last indefinitely.

Fire performance

30mm Kingspan Insulation TF70 has an F Euroclass rating under System 4 AVCP. When utilized in pitched roof constructions and placed under a suitable roof covering, it can fulfill national criteria for external fire exposure.
