52.5mm Kingspan Kooltherm K118 Insulated Plasterboard

52.5m K118 by Kingspan Kooltherm is an innovative insulated plasterboard with superior insulation properties designed for mechanically fixed and adhesively bonded insulated drylining applications. It enables the creation of remarkably slim wall constructions while providing exceptional insulation capabilities with a thermal conductivity of 0.019 W/mK. With its all-in-one design, it functions as both insulation, drylining, and vapor control, and can be applied to solid stonework and brickwork, with or without pre-existing lining.

The 52.5mm Kooltherm Kingspan boasts several highlights, including its status as one of the thinnest Internal Wall Insulation (IWI) materials, making it ideal for buildings where internal space retention is critical, and its suitability for structures that cannot be insulated externally. Additionally, its all-in-one design provides insulation, drylining, and vapour control, while allowing for quick response heating, and its lightweight composition makes it simple to transport, handle, and install.

Properties

Model: 52.5mm K118

Thickness: 52.5mm

Pack Quantity: 1 sheet

Pack Weight: 28.03kg

Dimensions: 2,400mm x 1,200mm x 52.50mm ( 40mm Phenolic PIR bonded to 12.5mm Plasterboard)

Length: 2400mm

Width: 1200mm

Compressive Strength: >100 (kPa)

Material: Phenolic core ǀ Gypsum plasterboard

R-Value: 2.10m2K/W

Thermal Conductivity: 0.019 W/mK across all thicknesses.

Fire Classification: Euroclass C-s1, d0

Coverage: 2.88m2

Insulation Material: 52.5mm Kooltherm K118 is a premium performance, lower-lambda rigid thermoset phenolic pir insulation.

Finish: Kraft facing ǀ Composite foil

Front Facing: The front facing of 52.5mm K118 is a tapered edge gypsum based plasterboard which readily accepts dryjointing materials and plaster skim.

Reverse Facing: The reverse facing of Kingspan K118 is a low emissivity composite foil, autohesively bonded to the insulation core during manufacture.

Applications: Internal Walls ǀ Roofs ǀ Ceilings

BBA Certified: Yes (no. 16/5299)

Vapour Control Layer: Yes, build in

Fixing method: Dot and Dab ǀ Mechanically Fixed

Decoration: Skim plaster

Features: Premium performance insulated plasterboard

About

This premium rigid thermoset 52.5mm phenolic insulation boasts a thermal conductivity of 0.019 W/mK and functions as insulation, drylining, and vapor control all in one board. It allows for quick response heating, is impervious to air infiltration, and resists the passage of water vapor. It is easy to handle and install and is suitable for use in new build, retrofit, and refurbishment projects. Additionally, it is a non-deleterious material manufactured with a blowing agent that has zero ODP and low GWP.

Applications

Kingspan 52.5mm is suitable for a variety of construction applications, including Cavity Masonry Wall Constructions, solid walls, timber frame walls, ceilings, metal furring systems, fixing to timber framing/battens, mechanical fixing directly to masonry substrates, and ceiling linings for both horizontal and sloping surfaces.

Benefits of Kooltherm

By utilising Kingspan k118 insulated plasterboard slim design, you can increase the amount of lettable space available within a property, thereby enhancing its lifetime value and overall desirability to potential buyers or renters.

Sustainability

As a company, we have integrated Kooltherm into our Planet Passionate sustainability initiative.

The core

Kingspan 52.5mm K118 insulated plasterboard consists of a high-performance, rigid, thermoset, fiber-free phenolic insulation core, which is manufactured with a blowing agent that has zero Ozone Depletion Potential (ODP) and low Global Warming Potential (GWP).

About Kingspan Insulation

Kingspan 52.5mm Insulation Ltd belongs to the Kingspan Group plc, a renowned manufacturer of construction products in Europe. The Kingspan insulation Group was established in the late 1960s and is a publicly traded group headquartered in Kingscourt, County Cavan, Ireland.
