CERESIT® CT325 is a reinforcing mesh designed for embedding into reinforcing mortars within CERESIT External Thermal Insulation Composite Systems (ETICS). For façades or pedestals subjected to higher mechanical loads, it is recommended to use Ceresit CT 325 in two layers or opt for a higher density mesh of 330 g/m². The available pack size is 1.1 meters in width and 50 meters in length.

Product specification

• Roll width: 110 cm
• Roll length: 50 m
• Roll coverage: 55.00
• Weight/m2: 0.16kg
• Mesh size: 4x4mm
• Warp: 24x2 per 100 mm
• Weft: 22 per 100 mm
• Colour: Dark Green
• Base: E-Glass fabric
• Weave: gauze, which prevents movement of the grid
• Treated fabric weight: ≥160 g/m2
• Mesh square dimensions: 4.0 mm × 4.0 mm
• Standard condition: 2075 N/5cm 2180 N/5cm
• After 28 days in 5 % NaOH: 1195 N/5cm 1220 N/5cm
• Longitudinal elongation: < 3.3 %
• Lateral elongation: < 2.7 %
• Amount required: approx. 1.1 m/m2
• Storage: in a dry place, from -10°C to +50°C, upright, free from pressure

FEATURES AND BENEFITS

Ceresit Reinforcing mesh for Ceresit Ceretherm External Thermal Insulation Composite Systems.

PROPERTIES

• Alkali-resistant
• Slipproof
• Tearproof

Scope of Use

Reinforcing mesh for embedding into reinforcing mortars within Ceresit CT325 External Thermal Insulation Composite Systems (ETICS). For façades or pedestals exposed to higher mechanical loads, it is recommended to use CT 325 in two layers or a higher density mesh of 330 g/m².

Application

1. Spread the prepared Ceresit reinforcing mortar evenly over the surface of the boards using a toothed trowel with 10-12mm teeth.
2. For mineral wool boards, apply a "priming" layer of mortar before distributing the main layer.
3. Immediately place the fiberglass mesh onto the prepared layer.
4. Embed the mesh using a metal trowel, smoothing it out completely. The properly applied mesh should not be visible and should be fully embedded in the mortar.
5. Ensure mesh overlaps on adjacent strips by about 10 cm. Avoid aligning mesh overlaps with the joints between the panels.
6. For corner holes in the walls (e.g., windows), embed additional mesh pieces diagonally, measuring approximately 20 x 30 cm.

More Information on Ceresit CT325 Glass-Fibre Mesh

• Manufaturer Link: Ceresit CT325 Glass-Fibre Mesh
