100mm Unilin Safe-R SR/CW Phenolic Partial Fill Cavity Insulation Board ( Pack of 4 )

100mm Unilin Safe-R SR/CW Phenolic Partial Fill Cavity Insulation Board is designed for traditional masonry walls and achieves outstanding U-Values. It accomplishes this while preserving a residual cavity, which provides protection against wind-driven rain.

Product Details

Brand: Xtratherm®

Model: 100mm SR/CW Cavity Wall Insulation

Thickness: 100mm

Length: 1200mm

Width: 450mm

Pack Quantity: 4

Board Coverage: 0.54m2

Pack Coverage: 2.16m2

Pack Weight: 8kg

Dimensions: 1,200mm x 450mm x 100mm

Compressive Strength: >100 (kPa)

Material: Phenolic resins

Profile: Square Edge

R-Value: 5.0m2K/W

Thermal Conductivity: 0.021W/mK

Fire Classification: Euroclass D s1 d0

Finish: Low emissivity foil facings

Inner facing: Foil facing

Outer facing: Foil facing

Shipping method: Articulated Vehicle ǀ Courier

Applications: Traditional masonry walls

BBA Certified: Yes (no. 10/4803)

Vapour Control Layer: Yes, build in

Features: BRE Green Guide A+ Rated

About

100mm Unilin SR/CW Phenolic Partial Fill Insulation Board is the preferred choice for achieving the reduced U-Values mandated by building regulations, all while preserving a residual cavity as a safeguard against wind-driven rain. Partial fill masonry walls represent the prevailing construction method for traditional buildings, and 100mm SR/CW phenolic insulation offers a viable solution when striving for lower U-Values is essential.

The impressive performance-to-thickness ratio of 100mm SR/CW cavity wall insulation facilitates the attainment of excellent U-Values within traditional structures without significantly increasing the overall wall width. The utilization of 100mm SR/CW allows for the retention of the residual cavity, serving as an effective barrier against moisture infiltration.

Advantages

1. Utilizes Phenolic Insulation
2. Preserves a clear cavity
3. Provides defense against wind-driven rain
4. Incorporates lower lambda values for enhanced U-Values
5. 100mm partial fill insulation board

Handling, Cutting, and Storage:

1. Xtratherm Cavity insulation must be stored on a clean, level surface that is raised off the ground. It should also be stored under protective cover.
2. Please note that the polythene wrapping alone is insufficient for safeguarding the insulation against exposure to the elements.
3. Exercise caution to ensure the insulation remains undamaged both during storage and throughout the construction process.
4. When handling the insulation board, always wear the appropriate personal protective equipment (PPE).

Certification and Standards:

1. BBA Certification Number: 10/4803.
2. Compliance with BS EN ISO 9001 Quality Management System.
3. Adherence to BS EN ISO 14001 Environmental Management System.
4. Conformance with BS EN 13166 standards.

Info

Have a browse of our Unilin stock and filter by thickness or coverage on the left-hand side of the page. If you’d like to talk through the suitability of some products for your project, or get a quantity discount quotation please call us by phone on +4402039519012 , email sales@insulationstoreonline or Live Chat - Lowest UK Insulation board Prices.
