106mm Unilin XtroLiner XO/STP PIR Soffit Plus Insulation Board ( Pack of 10 )

106mm Unilin XtroLiner XO/STP PIR Soffit Plus Insulation Board offers efficient solutions for thermal and fire performance needs in structural ceiling insulation applications for both commercial and residential buildings.

This advanced product features a modified 100mm PIR insulation board known for its exceptional performance. It comes with textured aluminum foil facings that have low emissivity, enhancing its insulating properties. The 100mm pir insulation board is securely bonded to a sturdy 6mm building Board with high impact resistance. This not only ensures durability but also provides a dependable surface for easy maintenance. Moreover, the panel serves as a solid base to which a decorative finish can be effortlessly added.

Product Details

Brand: Unilin®

Model: 106mm Soffit PLUS

Thickness: 100mm PIR insulation bonded to 6mm Building Panel

Dimensions: 2,400mm x 1,200mm x 106mm

Length: 2400mm

Width: 1200mm

Pack Coverage: 28.80m2

Pack Quantity: 10 sheets

Material: PIR ǀ Building Board

Profile: Square Edge

R-Value: 4.75m2K/W

Thermal Conductivity: 0.021W/mK

Compressive Strength: >120 (kPa)

Fire Classification: Euroclass B-s1, d0

Board Type: Superior performance PIR Insulation

Type of finishing board: 6mm Building panel

Inner facing: Foil Facing

Outer facing: Foil Facing

Shipping method: Articulated Vehicle ǀ Courier

Applications: Structural Ceiling ǀ Soffit Insulation

BBA Certified: Yes (no. 12/4956)

Vapour Control Layer: Incorporated

Features: Decorative finish may be applied

Manufacturer: Unilin Xtroliner®

Highlighted Features

1. Durable 6mm building panel with exceptional impact resistance
2. Improved fire protection capabilities
3. Compatible with various decorative finishes
4. Minimized thermal bridging effects
5. Lower lambda value leading to enhanced U-Values

Handling, Cutting, and Storage Guidelines

1. 106mm XtroLiner XO/STP Soffit Insulation Board must be stored indoors on a clean, flat surface, and kept above ground level. Adequate cover should be provided to shield it from external elements.
2. Note that the polythene wrapping alone is insufficient to protect the insulation when exposed to outdoor conditions.
3. Exercise caution to safeguard the pir insulation Board during both storage and the construction process.
4. Always use appropriate Personal Protective Equipment (PPE) when handling the insulation.

Certifications and Standards

1. Holds BBA Certification No.12/4956.
2. Conforms to the BS EN ISO 9001 Quality Management System.
3. Adheres to the BS EN ISO 14001 Environmental Management System.
4. Complies with BS EN 13165 standards.

Typical Fixings Patterns
