110mm Unilin Safe-R SR/FB Framing Insulation Board ( Pack of 3 )

The 110mm Unilin Safe-R SR/FB Framing Insulation Board has been specifically engineered for applications involving steel or timber frames up to a height of 11 meters. It boasts a Euroclass C Fire Classification, making it a versatile choice for use as either an insulated sheathing board or for placement between studs. Employing the 110mm SR/FB Framing Insulation Board offers exceptional U-Values and enhanced Thermal Bridging detailing, ensuring top-notch performance in your construction projects.

Product Details

Brand: Xtratherm/Unilin®

Model: 110mm SR/FB Framing Board

Thickness: 110mm

Length: 2400mm

Width: 1200mm

Dimensions: 2,400mm x 1,200mm x 110mm

Board Coverage: 2.88m2

Pack Coverage: 8.64m2

Pack Weight: 21kg

Pack Quantity: 3

R-Value: 5.5m2K/W

Thermal Conductivity: 0.021W/mK

Compressive Strength: >100 (kPa)

Type: Phenolic Insulation Board

Profile: Square Edge

Fire Classification: Euroclass C s1 d0

Finish: Low emissivity foil facings

Inner facing: Foil facing

Outer facing: Foil facing

Shipping method: Articulated Vehicle ǀ Courier

Applications: Steel and Timber Frame

BBA Certified: Yes (no. 10/4803)

Vapour Control Layer: Yes, build in

Foil faced: Both sides

Features: Superior Performance Insulation

Benefits

1. Appropriate for application in steel or timber frame systems with a maximum height of 11 meters.
2. Featuring a lower lambda value to enhance U-Values.
3. Holds a Fire Classification of C-s1, d0.
4. Minimizes Thermal Bridging.

Handling, Cutting, and Storage:

1. Xtratherm Framing Insulation Board must be stored on a clean, level surface that is raised off the ground. It should also be stored under protective cover.
2. Please note that the polythene wrapping alone is insufficient for safeguarding the insulation against exposure to the elements.
3. Exercise caution to ensure the insulation remains undamaged both during storage and throughout the construction process.
4. When handling the insulation board, always wear the appropriate personal protective equipment (PPE).

Certification and Standards:

1. BBA Certification Number: 10/4803.
2. Compliance with BS EN ISO 9001 Quality Management System.
3. Adherence to BS EN ISO 14001 Environmental Management System.
4. Conformance with BS EN 13166 standards.
