120mm Unilin Xtroliner XO/FB Steel and Timber Frame Insulation ( Pack of 3 )

120mm Unilin Xtroliner XO/FB Framing Board has been created to cater to diverse construction needs, encompassing both steel and timber frame applications, with heights reaching up to 11 meters. This versatile 120mm framing board can serve a dual purpose - fitting snugly between studs or functioning as an insulated sheathing board. Incorporating 120mm XO/FB Framing Board in such scenarios yields a direct reduction in Thermal Bridging effects commonly associated with steel or timber studs.

Product Details

Brand: Unilin®

Dimensions: 2,400mm x 1,200mm x 120mm

SKU: 120mm XO/FB

Thickness: 50mm, 60mm, 75mm, 80mm, 100mm, & 120mm

Compressive Strength: 120 (kPa)

Length: 2400mm

Width: 1200mm

Pack Quantity: 3

Pack Coverage: 8.64m2

Material: 120mm PIR Insulation (polyisocyanurate)

Profile: Square Edge

R-Value: 5.70m2K/W

Thermal Conductivity: 0.021W/mK

Compressive Strength: >120 (kPa)

Density: 32kg/m3

Fire Classification: Euroclass C-s2, d0

Finish: Robust Textured Foil

Inner facing: Foil Facing

Outer facing: Foil Facing

Shipping method: Articulated Vehicle ǀ Courier

Applications: Timber or Steel Framing Systems

BBA Certified: Yes (no. 12/4956)

Vapour Control Layer: Incorporated

Foil faced: Yes, Both sides

Features: Reduced Thermal Bridging

Manufacturer: Xtratherm Xtroliner®

Highlighted Features

1. Applicable for both Steel and Timber Frame Systems
2. Lower lambda value contributing to enhanced U-Values
3. Suitable for both Newbuild and Renovation projects
4. Reduced Thermal Bridging effects
5. Sturdy Textured Foil construction
6. 120mm framing wall insulation board

Specification Clause

The chosen wall insulation will be 120mm XtroLiner XO/FB, produced in compliance with EN 13165 by Unilin Insulation. This wall insulation solution consists of a durable modified Polyisocyanurate (PIR) core enclosed by textured, robust, low emissivity foil facings. The specific variant, XtroLiner 120mm XO/FB_ _ _mm, exhibits an Agrément declared Lambda value of 0.021 W/mK.

Resistance ‘R’ Values

The resistance value of any thickness of Unilin 120mm PIR insulation can be ascertained by simply dividing the thickness of the material (in metres) by its agrément declared lambda value, for example: Lambda 0.021 W/mK and thickness 80mm -> 0.080/ 0.021 -> R-Value = 3.80. In accordance with EN 13165, R-Values should be rounded down to the nearest 0.05 (m2K/W).

Guidelines for Handling, Cutting, and Storage

1. To ensure proper storage, 120mm Xtratherm XO/FB insulation should be placed on a clean, flat surface above ground level and kept under cover.
2. Note that relying solely on the polythene wrapping is insufficient to shield the insulation from outdoor conditions.
3. Vigilance is required to safeguard the insulation during storage as well as throughout the construction phase.
4. Always wear suitable Personal Protective Equipment (PPE) when handling insulation materials.
