126mm Unilin Safe-R SR/STP Phenolic Soffit Plus Board ( Pack of 9 )

The 126mm Unilin Safe-R SR/STP Phenolic Soffit Insulation Board offers reliable thermal and fire performance solutions for use in structural ceiling applications within both commercial and residential buildings. This high-performance 120mm phenolic insulation board, featuring low emissivity aluminum foil facings, is securely bonded to a 6mm building panel. This design ensures not only a durable and easily maintained surface but also allows for the application of decorative finishes if desired.

Product Details

Brand: Xtratherm/Unilin®

Model: 126mm SR/STP Soffit Board

Thickness: 126mm - 120mm Phenolic insulation + 6mm Building Panel

Length: 2400mm

Width: 1200mm

Pack Quantity: 9

Board Coverage: 2.88m2

Pack Coverage: 25.92m2

Pack Weight: 270kg

Dimensions: 2,400mm x 1,200mm x 126mm

Compressive Strength: >120 (kPa)

Material: Phenolic resins ǀ Building Panel

Profile: Square Edge

R-Value: 6.0m2K/W

Thermal Conductivity: 0.021W/mK

Fire Classification: Euroclass B s1 d0

Profile: Straight

Inner facing: Foil facing

Outer facing: Foil facing

Type: Phenolic Insulation

Type of finishing board: 6mm Building panel

Shipping method: Articulated Vehicle ǀ Courier

Applications: Structural Ceiling ǀ Soffit

BBA Certified: Yes (no. 10/4803)

Vapour Control Layer: Yes, build in

ETA Notification: Yes

Features: Accepts Decorative Finish

About

1. 126mm Unilin Safe-R SR/STP Phenolic Soffit insulation Board offers versatile installation options: it can be directly affixed to the concrete slab, installed onto battens, or used with proprietary fixing systems to ensure a smooth and level surface. This lightweight and rigid product is user-friendly, making installation quick and effortless.
2. The bonded facing of the non-combustible building panel offers both water and impact resistance, ensuring long-lasting protection for the application of decorative finishes.
3. When employing 126mm Safe-R Soffit Plus in soffit areas, be it in new construction or refurbishment projects, it delivers optimal U-Values with minimal insulation thickness. This product achieves an impressively low thermal conductivity of 0.020 W/mK and boasts a Euroclass B fire classification.

Advantages

1. Sturdy 120mm Phenolic insulation + 6mm building panel with excellent impact resistance.
2. Fire Classification B-s1, d0 compliant, enhancing safety.
3. Compatible with decorative finishes for aesthetic flexibility.
4. Minimized thermal bridging for improved energy efficiency.
5. Lower lambda value contributing to enhanced U-Values.

Handling, Cutting, and Storage:

1. Xtratherm Soffit insulation must be stored on a clean, level surface that is raised off the ground. It should also be stored under protective cover.
2. Please note that the polythene wrapping alone is insufficient for safeguarding the insulation against exposure to the elements.
3. Exercise caution to ensure the insulation remains undamaged both during storage and throughout the construction process.
4. When handling the insulation board, always wear the appropriate personal protective equipment (PPE).

Certification and Standards:

1. BBA Certification Number: 10/4803.
2. Compliance with BS EN ISO 9001 Quality Management System.
3. Adherence to BS EN ISO 14001 Environmental Management System.
4. Conformance with BS EN 13166 standards.

Info

Have a browse of our Unilin stock and filter by thickness or coverage on the left-hand side of the page. If you’d like to talk through the suitability of some products for your project, or get a quantity discount quotation please call us by phone on +4402039519012 , email sales@insulationstoreonline or Live Chat - Lowest UK Insulation board Prices.
