25mm Kingspan Thermaroof TR27 Flat Roof Insulation ( Pack of 12 )

25mm Kingspan Thermaroof TR27 stands as a top-tier flat roof insulation solution, designed for application on roofs with fully adhered single-ply, partially bonded built-up felt, mastic asphalt, or cold liquid applied waterproofing. This high-performance insulation is perfectly compatible with a wide range of green roof systems, offering ease of handling and installation. Whether it's a new construction or a renovation project, 25mm Kingspan TR27 is the ideal choice.

The TR27 25mm board measures 600mm by 1200mm, while the range of thicknesses from 40mm to 150mm comes in a size of 1200mm by 1200mm.

Product Specification

Brand: Kingspan

Model: 25mm Thermaroof TR27

Thickness: 25mm

Length: 1200mm

Width: 600mm

Weight: 7.00kg

Pack Quantity: 12 sheets

Board Coverage: 0.72m2

Dimensions: 1,200mm x 600mm x 25mm

Colour: Light Yellow | Brownish

Compressive Strength: 150kPa

Density: 32kg/m3

Profile: Square edge

R-Value: 0.93m2K/W

Has a thermal conductivity of: 0.027 W/mK (insulant thickness < 80 mm) 0.025 W/mK (insulant thickness 80 - 119 mm) 0.024 W/mK (insulant thickness ≥ 120 mm)

Finish: Faced on both sides with a coated glass tissue, autohesively bonded to the insulation core during manufacture.

Insulation Material: A high performance rigid thermoset polyisocyanurate (PIR insulation).

Application Temperature: from +5 °C to +25 °C

Shipping method: Articulated Vehicle ǀ Courier

Applications: Insulation for flat roofs waterproofed with fully adhered single-ply, partially bonded built-up felt, mastic asphalt and cold liquid applied waterproofing.

BBA Certified: Yes

Fire Reaction: Under System 4 AVCP, 25mm Thermaroof TR27 has a Euroclass rating of F.

Compressive Strength: typically exceeds 150 kPa at 10% compression.

Features: High performance flat roof insulation board

Product Highlights:

1. Offers exceptional thermal efficiency, ranking among the most efficient insulation products for flat roofs.
2. Fully compatible with single-ply non-bituminous membranes, ensuring a seamless fit when bonded with solvent-based adhesive systems.
3. Compatible with a wide range of bitumen-based and mastic asphalt waterproofing systems, providing versatility in installation options.
4. Compatible with most green roof systems, allowing for integration with eco-friendly roofing solutions.
5. Available with FM Approval to FM 4470, ensuring compliance with industry standards.
6. Also available as a tapered insulation system, facilitating proper drainage by creating a slope in the roof design.
7. Easy to handle and install, simplifying the installation process and saving time.
8. Pre-bonded boards (TR27PB) are available, reducing installation time further. Contact our roofing Insulation team for additional information and assistance.

Applications

25mm Kingspan TR27 offers versatile installation options to suit various scenarios. Some of the recommended methods include:

1. Dense Concrete Deck with Suspended Ceiling: Ideal for installations where a dense concrete deck is present, along with a suspended ceiling system.
2. Timber Deck with Plasterboard Ceiling: Suitable for installations where a timber deck is utilized, accompanied by a plasterboard ceiling.
3. Metal Deck with No Ceiling: Designed for metal deck applications without the need for a ceiling system.
4. Extensive Green Roof Covering - Metal Deck with No Ceiling: Specifically tailored for extensive green roof systems on metal decks without a ceiling.
5. Semi-intensive Green Roof Covering - Dense Concrete Deck with Suspended Ceiling: Specifically designed for semi-intensive green roof systems, with a dense concrete deck and suspended ceiling configuration.
6. These different methods provide flexibility to accommodate diverse building structures and design requirements.
