30mm Unilin Thin-R XT/TF Timber Framed Walls

Timber Frame construction is a style of building construction that uses heavy timbers to frame the structure. The external structural wall of a timber frame building includes timber studs that carry the loads imposed before transmitting them to the foundations. The walls, floors, and roofs of timber frame buildings are designed as a whole, coherent engineered structure.

30mm Unilin ( Xtratherm )Thin-R XT/TF Timber Frame Systems bring timber framed wall insulation performance to new levels, surpassing the default values asked for in current building regulations. Using 25mm XT/TF in timber framed walls helps achieve Future Home and Passive House Standards

Product Specification

Brand: Unilin / Xtratherm®

Thickness: 30mm

Thickness: 25mm, 30mm,40mm, 50mm, 60mm, 80mm, 100mm, 120mm

Dimensions: 2.4m x 1.2m x 30mm

Area: 2.88m2

Density: 30kg/m3

Thermal Conductivity: 0.022W/mK

Thermal Resistance: 1.50 m2K/W

Compressive Strength: 140kPa

Water vapour resistivity: 100MN.s/g.m

Surface Spread of Flame: Class 1

Type: PIR Insulation for timber frame walls

Application: Wall Insulation

Inner facing: Foil Facer

Outer facing: Foil Facer

Compressive Strength: CS (10\Y) 140

Reaction to Fire: Euroclass E

EPD: An Environmental Product Declaration (EPD), certified by IGBC is available for this product.

Key Points of 30mm Unilin XT/TF

1. Rapid Build System
2. Approved for use with Fibre in stud
3. Suitable for Newbuild and Renovation
4. Reduced Insulation Thickness
5. Low Emissivity Foil Facings

Info

Have a browse of our Xtratherm stock and filter by thickness or coverage on the left-hand side of the page. If you’d like to talk through the suitability of some products for your project, or get a quantity discount quotation please call us by phone on +4402039519012 , email sales@insulationstoreonline or Live Chat - Lowest UK Insulation Prices.
