40mm Recticel Eurothane GP PIR Rigid Insulation Board

40mm Recticel Insulation Eurothane® GP is a lightweight PIR insulation board with high performance, designed to be simple to cut, handle, and install. It is a versatile solution that is ideal for various applications, such as pitched roofs, framed walls, and floors. Contractors and installers find 40mm Eurothane GP to be the perfect choice because of its excellent thermal performance, with a low thermal conductivity of λ = 0.022 W/mK. Additionally, it offers the advantage of quick and effortless installation.

Properties

Brand: Recticel®

Model: 40mm Eurothane GP

Thickness: 40 mm

Dimensions: 2,400mm x 1,200mm x 40 mm

Length: 2400mm

Width: 1200mm

Density: 30kg/m3

Weight: 3.46kg

R-Value: 1.80 m2K/W

Thermal Conductivity: 0.022 W/mk

Material: Polyisocyanurate | PIR Insulation

Compressive Strength: 25-49mm: 120 kPa | 50-160mm: 140 kPa

Vapour Resistivity: 100 MNs/gm

Finish: Gas diffusion tight multilayer foil on both sides and grid on both sides.

Edge finishing: Square edges

Fire performance: Euroclass F

Applications: Thermal insulation of Pitched roofs, Framed walls, Floors (compatible with underfloor heating systems).

Features: Reduce the heating and cooling costs

Model: 40 mm Eurothane GP

How to insulate Pitched Roofs with Eurothane® GP?

Professional installers highly favor Eurothane® GP 40mm insulation boards due to their lightweight design, ease of installation, and ability to be efficiently cut on site. When laying the boards, it is recommended to align the long edges parallel to the rafters and tightly butt them together in a brick-bond pattern. For board joints running from eaves-to-ridge, it is crucial to support them with rafters. Before counter battening, boards can be temporarily fixed with nails.

How to insulate Framed Walls with Eurothane® GP?

The 40mm PIR insulation boards are fitted in a tightly butted brick-bond pattern between the framed wall battens.

How to insulate floors with Eurothane® GP?

When installing the Eurothane boards, they should be laid in a tightly butted brick-bond pattern. If the desired insulation thickness requires two layers, it is essential to stagger the board joints and position the thicker layer on the outermost side.

Recticel PIR The Advantages

Our 40mm Insulation is manufactured to the highest standards, making the installation process significantly easier. With precision cut straight edges, consistent board sizes, high compressive strength, and a super-flat surface finish, our boards provide a quicker, easier, and more cost-effective installation. For a trouble-free, perfect build, trust Recticel PIR insulation.

Floor Advantages

Selecting the appropriate ground Floor Insulation requires consideration of both thermal and mechanical properties. Recticel 40mm PIR is an excellent choice for both domestic and commercial buildings, providing the required low thermal conductivity and high compressive strength for various floor constructions. As underfloor heating remains a popular feature in modern flooring, Recticel PIR excellent pipe clip retention makes it the perfect option.

Recticel's PIR insulation is not limited to ground applications. Eurothane FP is an excellent choice for lining the soffit of an intermediate floor above a basement or car park, providing the same exceptional thermal performance combined with a Class 0 spread of flame rating.
