77.5mm Unilin / Xtratherm Insulated Plasterboard XT/TL-MR Thermal Liner (Moisture Resistant)

Unilin Insulation | The new name for Xtratherm Insulation in the UK & Ireland.

The 77.5mm XT/TL-MR Thin-R Thermal Liner (Moisture Resistant) consists of a Unilin 65mm PIR insulation core and a composite foil facing bonded to 12.5mm tapered edge moisture resistant plasterboard, making it an insulated composite panel suitable for internal walls, sloped roofs, and ceilings. Suitable for both Dot&Dab and Mechanicall Fixed applications.

Both sides of the 77.5mm Insulated Plasterboard feature a insulated panel combined of PIR rigid insulation foam core bonded to 12.5mm green moisture resistant plasterboard designed for internal building areas of high humidity conditions, ideal for receiving a plaster finish or for direct decoration.

Properties

Brand: Xtratherm / Unilin

Thickness: 77.5mm overall

Model: 77.5mm XT/TL-MR Moisture Resistant

Dimensions: 2,400mm x 1,200mm x 77.5 mm

Compressive Strength: 150 kPa

Density: 30-32 Kg/m3

Length: 2400mm

Material: PIR core ǀ Moisture Resistant plasterboard

Profile: Moisture Tapered edge plasterboard

R-Value: 3.01 m2K/W

Thermal Conductivity: 0.022 W/mk

Vapour Resistivity: 100 MNs/gm

Finish: Composite Kraft facings

Reaction To Fire: Euroclass B s1 d0

Applications: internal walls, sloped roofs, ceilings, Kitchen & Bathrooms.

Vapour Control Layer: Yes, build in

Fixing method: Mechanically Fixed | Dot and Dab

Features: Moisture Resistant Insulated Plasterboard

Type: Thermal Liner®

Flexural Strength: ≥160N Transverse / ≥400N Longitudinal

Benefits

1. Insulation & Drylining in one application
2. Provides effective vapour control layer
3. Reduced insulation thickness
4. Suitable for a variety of wall Insulation types

About

77.5mm Thermal Liner XT/TL-MR is designed to provide high levels of thermal insulation and drylining in one operation, providing the solution of choice in newbuild and refurbishment projects. It improves energy efficiency of your home and has many benefits, including reduced energy costs and improved living conditions.

77.5mm Insulation Board is chemically inert and safe to use manufactured with a blowing agent that has zero Ozone Depletion Potential (ODP) and low Global Warming Potential (GWP).

Investing in the energy efficiency of your home can have numerous benefits, including lower energy costs and improved living conditions. The Xtratherm/Unilin XT/TL-MR Thermal Liner is an effective way to help achieve these goals and make your home more energy efficient.

The PIR board also provides a level of fire resistance due to the continuous adhesive ribbons, especially around openings, such as those around windows and doors.

What are Insulated Plasterboards?

The 77.5mm XT/TL-MR insulated plasterboards ( 65mm insulation + 12.5mm Moisture plasterboard ) are a type of building material that combines plasterboard with an insulation layer, typically made from PIR Insulation. The insulation layer is bonded to the plasterboard to create a single, multi-functional panel that provides both insulation and a finished surface. They are often used in construction to improve thermal and sound insulation, as well as to simplify and speed up the installation process. They are commonly used in walls, ceilings, and floors, and can come in a variety of sizes and thicknesses to suit different building requirements.
