100mm Unilin ECO360/CW Partial Fill Cavity Wall PIR Insulation Board ( Pack of 4 )

100mm Unilin ECO360/CW Partial Fill Cavity Wall PIR Insulation Board stands as a bio-enhanced solution for partial-fill cavity wall insulation, designed to optimize performance. This system boasts sturdy facings, precisely engineered jointing mechanisms, preformed corners, and an impressive Lambda value of 0.020 W/mK.

100mm Unilin Partial Fill Cavity Wall PIR Insulation Board embodies an eco-conscious choice for Passive and low-energy construction projects. It has the capacity to attain an outstanding Passive U-Value of 0.15 W/m2K when integrated into a conventional cavity wall.

When you choose to construct with 100mm ECO360 Partial Fill Cavity Wall PIR Insulation Board, you maintain a residual cavity that serves as a formidable defense against wind-driven rain, ensuring excellent protection for your building.

Product Details

Model: Cavity Wall 360

Length: 1200mm

Width: 450mm

Thickness: 100mm

Pack Quantity: 4

Board Coverage: 0.54m2

Pack coverage: 2.16m2

Pack Weight: 8kg

Thermal Conductivity: 0.020W/mK

R-Value: 5m2K/W

Compressive Strength: 120kPa

Type: Bio enhanced high performance PIR Insulation

Inner facing: Foil facing

Outer facing: Foil facing

Applications: Partial fill cavity walls

Advantages:

1. Eco-Friendly 100mm PIR Insulation with Bio-Enhancements
2. Superior performance with a minimum of 0.020 W/mK thermal conductivity
3. Free from halogen components
4. Biodegradable packaging for sustainability
5. Maintained clarity within the insulation cavity
6. Reduced Lambda value to enhance U-Values
7. 100mm Partial Fill Insulation Board

Applications

1. Partial fill cavity walls

Handling, Cutting, and Storage:

1. Unilin Partial Fill Insulation must be stored on a clean, level surface that is raised off the ground. It should also be stored under protective cover.
2. Please note that the polythene wrapping alone is insufficient for safeguarding the insulation against exposure to the elements.
3. Exercise caution to ensure the insulation remains undamaged both during storage and throughout the construction process.
4. When handling the insulation board, always wear the appropriate personal protective equipment (PPE).

Certification and Standards:

1. BBA Certification Number: 10/4803.
2. Compliance with BS EN ISO 9001 Quality Management System.
3. Adherence to BS EN ISO 14001 Environmental Management System.
4. Conformance with BS EN 13166 standards.

Info

Have a browse of our Unilin stock and filter by thickness or coverage on the left-hand side of the page. If you’d like to talk through the suitability of some products for your project, or get a quantity discount quotation please call us by phone on +4402039519012 , email sales@insulationstoreonline or Live Chat - Lowest UK Insulation board Prices.
