25mm Unilin FR/ALU Thin-R Flat Roof Insulation ( Pack of 12 )

25mm Unilin FR/ALU previous known as 25mm Xtratherm FR/ALU stands out as a top-tier Polyisocyanurate flat roof insulation featuring vapor-tight aluminum foil facings, making it compatible with single-ply membranes. It is an integral component within Unilin's extensive selection of high-performance flat roof boards, offering complete solutions for flat roof projects.

Product specification

Brand: Unilin Insulation FR/ALU known as Xtratherm FR/ALU

Model: 25mm Unilin FR/ALU

Thickness: 25mm

Thickness: 25mm, 30mm, 40mm, 50mm, 60mm, 70mm, 75mm, 80mm, 90mm, 100mm, 110mm, 120mm, 125mm, 130mm, 140mm, 150mm

Length: 2400mm

Width: 1200mm

Board Coverage: 2.88m2

Pack Coverage: 34.56m2

Pack Quantity: 12 sheets

Pack Weight: 35.92kg

Dimensions: 2,400mm x 1,200mm x 25mm

Thermal Conductivity: 0.022 W/mK

R-Value: 1.125 m2K/W

Colour: Light yellow

Density: 32 Kg/m3

Compressive Strength: > 150kPa

Material: Polyisocyanurate Rigid Foam ( PIR insulation board )

Profile: Square Edge

Fire Reaction: Euroclass B, s2-d0

Finish: Vapour resistant gas-tight foil

Inner facing: Foil Facing

Outer facing: Foil Facing

Applications: Flat Roof Waterproofing Systems

BBA Certified: Yes (No. 11/4817)

Fixing method: Mechanically fixed single ply waterproofing systems

Foil faced: Yes, gas-tight foil facings on both sides

Features: Composite gas-tight foil facings on both sides

Manufacturer: Unilin Insulation®

Main Highlights:

1. Exceptional Thermal Efficiency
2. Foil facers providing effective vapor resistance
3. Suitable for mechanically fixed single-ply systems
4. This product has an Environmental Product Declaration (EPD) certified by IGBC. For additional information, please reach out to our technical support.

Advantages:

1. Exceptional Thermal Efficiency
2. Compatibility with mechanically fixed single-ply systems and loose-laid ballasted systems
3. Effective vapor resistance with foil facers
4. The product comes with an Environmental Product Declaration (EPD) certified by IGBC. For more information, please contact our technical support team.

About

The 25mm Unilin FR/ALU Thin-R Flat Roof Insulation Board is composed of a rigid polyisocyanurate PIR insulation board featuring gas-tight foil facings on both sides.

Designed for thermal insulation and enhancing slopes on restricted-access concrete, timber, or metal flat roof decks in both new and existing buildings, the 25mm Flat Roof Board FR/ALU serves a dual purpose.

When used in conjunction with a vapor control layer and a mechanically fixed single-ply roof waterproofing membrane, 25mm Unilin FR/ALU Insulation Board is optimized for performance.

Installation of FR/ALU flat roof boards involves laying them over the vapor control layer in a break-bonded pattern, providing effective coverage.

To ensure secure placement, 25mm Unilin Thin-R flat roof insulation boards should be affixed using approved mechanical fixings.

Roof Design

Consideration should be given to the recommendations of BS 4841: Part 3 and those of the Single Ply Roofing Association.

Falls

The fall on a flat roof should be constant and steep enough to ensure that rainfall does not pond.

Fire Performance

The fire rating, when tested to EN 13501-5 and BS 476 Part 3 ‘External Fire Exposure Roof Test’, will be dependent upon waterproofing system specified.

Note: This board was formerly known as 25mm Xtratherm Thin-R FR/ALU Flat Roof PIR Insulation Board
