52.5mm Speedline PIR Thermal Laminate Board

52.5mm Speedline insulated plasterboards are specifically crafted for enhancing thermal conductivity within properties. These boards consist of a fibre-free rigid polyisocyanurate (40mm PIR) core that is securely attached to a 12.5mm plasterboard during the manufacturing process. This innovative 2-in-1 product seamlessly integrates thermal insulation and dry-lining solutions into a single board, streamlining installation and improving efficiency.

Furthermore, these boards are manufactured with a strong commitment to environmental sustainability. They possess Zero Ozone Depletion Potential (ODP) and Zero Global Warming Potential (GWP), and are entirely free from CFC and HCFC, ensuring minimal impact on the environment.

The lightweight nature of these 52.5mm insulation boards makes them easy to handle, cut, and install. It is recommended to use a fine-toothed saw for cutting the insulated plasterboards. Additionally, you can use a plank of wood or a ruler as a cutting guide to ensure precise cuts and hold the board securely in place during cutting.

Properties

Thickness: 37.5mm, 52.5mm, 62.5mm, 72.5mm

Width: 1200mm

Length: 2400mm

Board Coverage: 2.88m2

Density: 250kg/m3

Weight of 1m2: 9.38kg

Weight: 27kg

Thermal Conductivity: 0.022 W/mk (insulation) 0.19 W/mk (plasterboard)

Thermal Resistance: 2.87m2K/W

Compressive Strength: 140kPa

Material: Polyisocyanurate ( PIR Insulation ), Low emissivity foil

Compressive Strength: Excess 140kPa at yield (insulation only)

Moisture Vapour Resistance: Installed Value at 100 MNs/g

Fire Performance: Class B s1,d0

Key Features:

1. Simplified solution for upgrading walls and roofs.
2. Cost and time-effective option.
3. Allows for thermal insulation and internal finish to be applied simultaneously.
4. Suitable for both new build and renovation projects.
5. Versatile applications across various needs.
6. Green Guide Rating A+ for environmentally friendly construction.
7. Long-lasting and durable construction.
8. Compliant with or exceeds current building regulations.
9. Mitigates condensation risks by providing vapor resistance and reducing thermal bridging.
10. Speedline Thermal Laminates can be finished using either 'Taping & Jointing' or gypsum skim plaster.

Applications

Speedline 52.5mm Insulated Plasterboards offer a wide range of applications, making them suitable for various construction projects. These applications include:

New Builds: Can be used in new construction projects to enhance the thermal performance of building elements.

Refurbishments: They are also ideal for refurbishment projects, where the aim is to improve the energy efficiency of existing structures.

Upgrading Existing Building Elements: Can be used to upgrade the thermal performance of walls or roofs in already constructed buildings.

Mechanical Fixing: They can be mechanically fixed onto timber battens for solid masonry walls, providing a secure and efficient installation method.

Speedline Wall Liner System: For solid masonry walls, these plasterboards can be mechanically fixed onto the Speedline Wall Liner System, offering a specialized solution for improved insulation.

Masonry Cavity Wall: Can be applied to masonry cavity walls, providing enhanced thermal insulation.

Pitched Roof Application: These plasterboards are suitable for pitched roof applications, helping to regulate the temperature and improve energy efficiency.

Flat Roof Application: Speedline 52.5mm can be used in flat roof applications to enhance insulation and minimize heat loss.

The versatility of Speedline Insulation boards allows them to be utilized in a wide range of construction scenarios, providing effective thermal insulation solutions.
